TSO Products 61-467 TDS-13 Low Profile Dog Stops

TDS-13 Low Profile Dog Stops
A versatile addition to your 20mm hole patterned worktop

If we could pick only one accessory for our 20mm hole patterned worktop, it just might be a pair of these TDS-13 Dog Stops purely for their versatility. Distinguished by their low profile of just 9.5mm (3/8") in thickness and extended length of 340mm (13-3/8"), a pair of our TDS-13s are a great solution for:

• Workpiece locating and general workholding. Need to cut a series of identically sized cabinet components? Measure just once, install a pair of TDS-13 Dog Stops and extend them so they contact your workpiece opposite the edge to be cut, and lock them in this exact position by securing two hex screws from the top. The TDS-13 retains its positioneven when removed or re-installed into your worktop.
• The ultimate material stop. Domino mortising, sanding, planing and scraping are all made easier with the TDS-13 used as an extended length material stop. Deploy a pair of TDS-13s in perpendicular positions to capture your workpiece along two edges, or use in conjunction with an inline clamp like our Power-Loc Toggle Clamp to completely immobilize it. At only 9.5mm (?) thick, you can comfortably sand, plane and scrape workpieces as thin as (12.7mm) without worrying about the TDS-13 interfering with your work.
• A 45 or 90 fence for precise cuts with your track saw. With its extended length, the TDS-13 can span four 20x96mm dog holes when positioned at 0 or 90, or three dog holes when positioned at a 45 angle. Its thin enough to fit under a guide rail, making it an ideal material stop for track sawing operations. Butt the ends of two TDS-13s together and you now have a contiguous fence measuring 680mm (26-) in length.
• Verify squareness. Position two TDS-13s in a perpendicular layout to quickly validate the squareness of a drawer box, or force it square during glue-up with an inline clamp.

Even when removed and re-inserted, the TDS-13 returns exactly to its original position thanks to the inclusion of two DoubleGroove Chamfer Dogs. Unlike traditional bench dogs which typically feature a large diameter collar that extends above the worktop, these dogs feature a small 45 chamfer allowing them to sit flush with your work surface. This design detail also allows us to make the TDS-13 as thin as possible.

• (2) TS10 Dog Stops
• (2) DoubleGroove 20mm Bench Dogs
• (2) M8 SpeedKnobs

• Weight: 3.00 LBS
