- Designed for intricate contour sanding operations
- 2 Step activation safety switch with line voltageinterruption in case of power failure
- Heavy-duty cast-iron tilting table is precision ground
- 1in. to 4in. rubber drums can be fitted on both endsfor full use of the entire spindle
- 4in. Dust chute for dust collector hook-up
- Heavy-duty oil bath gearbox with oil level sight gauge
- 10 interchangeable spindles (1/4in. x 5in., 3/8in. x 6in.,1/2in. x 6in., 5/8in. x 6in., 3/4in. x 9in., 1in. x 9in.,1-1/2in. x 9in., 2in. x 9in., 3in.x 9in. and 4in. x 9in.)
- Includes 3 interchangeable table insertsand adjustment keys
- Weight: 320.00 LBS
Oscillations Per Minute 75
Oscillations Stroke 1-1/2"
Spindle Drum Length 10 (5" To 9")
Spindle Drum Diameter 1/4" To 4"
Spindle Speeds 1,725 Rpm
Table Size 24-1/4" X 24-1/4"
Motor 10 Amp. @ 110V, 5 Amp. @ 220V
Voltage 110/220V, 1 Phase, 60 Hz
Pre-Wired At 110V
Assembled Dimensions (Lxwxh)/Weight 24-1/4" X 24-1/4" X 47-1/4" / 285 Lbs
Package Dimensions (Lxwxh)/Weight 26" X 26" X 44-1/2" / 320 Lbs
UPC 7-72995-15009-0
