- Powerful 2 HP motor
- Precision ground cast iron tables
- Ocillating sanding belt tilts from 0º - 90º instead of the table
- Features a non-oscillating spindle sander for contour sanding
- Balanced 7" aluminum drive wheel and 4" idler rubber wheel ensure positive grip
- Quick release sanding belt tension lever
- Graphite pad diminishes belt friction for increasedsanding belt life
- Two 4" dust chutes mounted on hinged safety guards provide optimal dust collection
- Magnetic safety switch and top mounted emergency stop button
- Includes miter gauge, work stop, three end-tableinserts and three 4-1/2" high spindle drums and sanding sleeves (1-1/2", 2", 3")
- Weight: 550.00 LBS
- Width: 32.00 (in)
- Height: 44.50 (in)
- Depth: 58.00 (in)
Belt6" X 108"
Table Size (Front)35-5/8" X 12"
Table Size (End Table)10" X 11-1/2"
Belt Speed3,150 SFPM
Belt Oscillations Stroke3/4"
Table Travel (Upward / Forward/Back)4" / 4-1/2"
Motor9.4 Amp.
Voltage220V, 1 Phase, 60 Hz
Assembled Dimensions (Lxwxh) / Weight60" X 28" X 49-1/2" / 485 Lbs
Package Dimensions (Lxwxh) / Weight58" X 32" X 44-1/2" / 550 Lbs
Upc7 72995 02203 8
