Now available for both DeWalt’s full-size 10" and compact 8-1/4" jobsite table saws! Select your saw model using the option at the top of this page.
Transform Your DeWalt Saw with this Precision Rip Fence
Take your DeWalt 8-1/4" or 10" jobsite table saw to another level with this Upgraded Rip Fence, designed to bring precision, versatility, and convenience to your woodworking projects. This affordable fence upgrade adds three T-slots—two on the face and one on the top—allowing you to easily mount essential accessories like stock guides, featherboards, sacrificial fences, and custom jigs. Installation is easy using DeWalt's original fence brackets, and the upgrade preserves all of your stock fence's original functionality.
Compact Jobsite Saws: DWE7485, DWE7480, DCS7485 or DW745
Key Features
- Triple T-Slot Design: Allows easy attachment of essential accessories like stock guides, feather boards, auxiliary fences, and custom jigs.
- Compatible with JessEm Stock Guides: Pair this fence with JessEm Clear-Cut FLEX Stock Guides to reduce the potential for kickback by simultaneously holding down and guiding material accurately against the fence.
- Build Your Own Jigs: Integrated T-slots allow for easy attachment of custom jigs like tenoning systems, tall fences for upright panel support, L-fences, and more. The possibilities are endless, giving you the flexibility to adapt the fence to your specific project needs.
- Easy Installation: This upgraded fence reuses the existing DeWalt brackets and hardware and shares the same overall dimensions, so you’ll retain all the original features of your stock rip fence, such as the secondary flip-over fence for narrow and wide rips, built-in push-stick clips, and secure under-saw storage for transport.
JessEm Stock Guide Compatibility
This fence is compatible with JessEm Clear-Cut FLEX Stock Guides. When installing these guides, be sure to use the metal spacers included with the fence kit. These spacers accommodate the longer threaded studs that JessEm uses for their stock guide’s locking knobs.
What's Included
- 1 qty. Upgraded Rip Fence
- 2 qty. Metal Spacers (for use with optional JessEm Clear-Cut FLEX Stock Guides)
- Thread Forming Screws (for re-installing DeWalt's front and back fence brackets)
Some assembly required.
Dimensions - Fence for Compact Saws (DWE7485, DWE7480, DCS7485, DW745)
- Fence
- Overall Length: 19.06" (484mm)
- Overall Height: 3.65" (93mm)
- Overall Thickness: 1.02" (25.9mm)
- Fence T-Slots - Upper Side Location
- Inside Width: 0.50" (12.7mm)
- Inside Depth: 0.34" (8.6mm)
- Opening: 0.33" (8.4mm)
- Fence T-Slots - Top & Lower Side Locations
- Inside Width: 0.50" (12.7mm)
- Inside Depth: 0.25" (6.4mm)
- Opening: 0.33" (8.4mm)
Dimensions - Fence for Full-Size Saws (DWE7491RS, DWE7492)
- Fence
- Overall Length: 22.00" (559mm)
- Overall Height: 3.78" (96mm)
- Overall Thickness: 1.00" (25.4mm)
- Fence T-Slots - Upper Side Location
- Inside Width: 0.57" (14.5mm)
- Inside Depth: 0.31" (7.9mm)
- Opening: 0.33" (8.4mm)
- Fence T-Slots - Top & Lower Side Locations
- Inside Width: 0.50" (12.7mm)
- Inside Depth: 0.25" (6.4mm)
- Opening: 0.33" (8.4mm)
Specifications
Compatibility: Fits DeWalt Compact Jobsite Saws (DWE7485, DWE7480, DCS7485, DW745) and Full-Size Jobsite Saws (DWE7491RS, DWE7492). Be sure to select the correct fence for your saw at the top of this page.
Material: Aluminum
Finish: Clear anodized
Weight - Fence for Compact Saws (DWE7485, DWE7480, DCS7485, DW745): 565g (1.3 lbs)
Weight - Fence for Full-Size Saws (DWE7491RS, DWE7492): 767g (1.7 lbs)
Recommended Mounting Hardware for Jigs: M6x1.0 Slide-In T-Nut (80/20 Inc. part number 3859 or equivalent)
