Chip protection mesh on vent slots. Low operating costs due to long tool life of punch and die. Rotating punch for up to 30% longer service life. QuickIN rapid change system. Stainless steel up to 24 gauge [0.6 mm]. Motor with outstanding performance and durability. 16 ft. [5 m] cable.
- Cutting Direction Setting Can Be Changed In 45 Deg. Increments Up To 360 Deg. Using Tool-free Rotating Cutting Head.
- 7.5 Ft./min [2.3 M/min] Cutting Speed For Excellent Performance.
- Optimum Ergonomics, Including A Motor Housing That Is Up To 20% Slimmer Due To An Extremely Narrow Drive Head.
Includes:
- 1 die for corrugated sheet metal (30109169009), mounted
- 1 punch (6 36 02 050 00 0)
- Weight: 6.20 LBS
- Width: 10.24 (in)
- Height: 3.54 (in)
- Depth: 15.75 (in)
Power consumption350 W
Power output210 W
Strokes1,000 - 1,800 spm
Cutting speed8 [2.3] ft/min[m/min]
Steel 58,000 lbf/in3/64 [1.3] in[mm]
Steel 87,000 lbf/in1/32 [0.8] in[mm]
Steel 116,000 lbf/in1/32 [0.6] in[mm]
Non-ferrous metals up to 36,000 lbf/in3/32 [2] in[mm]
Cutting width3/16 [4] in[mm]
Immersion Dia. with die3/4 [19] in[mm]
Radius of smallest curve (inside/outside)1/2 [15] / 3/4 [20] in[mm]
Cable with plug16 [5] ft[m]
Weight3.97 lbs
Videos Hide Videos Show Videos
- Weight: 6.20 LBS
- Width: 10.24 (in)
- Height: 3.54 (in)
- Depth: 15.75 (in)
