Bring digital precision to the craft of woodworking with Origin the handheld CNC router. Cut with unparalleled precision, flexibility and efficiency.
Origin is the worlds first hand-held CNC router. With onboard automatic cut correction, Origin makes precision cutting easy. Avoid the envelope limits of traditional CNC machines and tackle projects at a wide range of scales with a single, compact tool. With annual system updates and optional extensions, Origin is the only power tool that gets better with age. Create simple designs on the tool itself, or using Shaper Studio. You can also upload an existing design of your own. Additionally, Origin-ready files and hardware templates are available on ShaperHub.
- Automatic cut correction
- No programming required
- Intuitive touch screen interface
- On-tool design
- Suitable with a range of router bits
- Precise depth control
- Easy adjustments for tight fitting joints
- Cut perfect box joints and mortise and tenons
- Work at any scale
Bring digital precision to the craft of woodworking
- Work hands on with unparalleled accuracy, flexibility and efficiency.
Precise Joinery
- Combine Origin with Shaper Workstation to cut mortise and tenons, box joints, and other custom joinery with ease and precision.
Unmatched Portability
- Bring Origin to the job and work at any scale. Install virtually any hardware or inlay, and route pockets with minimal setup and maximum repeatability.
Easy Hardware Installation
- Cut perfect features for any piece of hardware. With ShaperHubs Hardware Catalog weve created over a hundred tested and verified free hardware templates from top manufacturers.
Origin Extensions
- Upgrade Origin with optional extensions specialized on-tool functions designed to increase productivity.
Advanced Joinery
- Add sophisticated elements and handcrafted details to solid wood projects and custom furniture.
Includes:
- Shaper Origin with Shaper SM-1 Spindle
- Tanos Systainer
- Two rolls of ShaperTape (150-ft each)
- Tool change accessories
- USB flash drive
- 1/4" upcut spiral cutter
- 1/8" upcut spiral cutter
- 60 degree engraving cutter
- Universal dust collection adapter
- SV1-AA Plate
- Weight: 26.00 LBS
Input Power120VAC, 60Hz. 7A
Spindle Motor720W brushed AC motor
10,000 - 26,000 RPM with load-compensating speed control
Soft-start, over-temperature and over-load safety cut-offs
Produced by Festool to Shaper specifications
ColletIncludes a 1/4" collet that accepts any commonly available 1/4" shank router bits
1/8" collet sold separately
Depth Control43mm (1.7") of total Z-axis travel
Digitally adjustable depth-of-cut
Automated touch-off sensor
Dust Extraction PortDesigned with the SM-1 spindle to provide optimal debris extraction
34mm inner diameter by 39mm outer diameter port dimensions
Fits most standard 27mm (35mm OD) and 36mm suction hoses (e.g. Festool, Fein)
Includes a 6.5' adaptor hose with a 2 1/4" OD nozzle for use with US-standard wet/dry vacs
ConnectivityWi-Fi enabled for transfer of design files via ShaperHub, and for receiving software updates
USB port allows easy offline transfer of design files
Digital Cut FilesWorks with standard vector files (.SVG)
Includes on-tool design capabilities
Touch ScreenCapacitive multi-touch full-color LCD
DimensionsOrigin: 13 3/4" (handle-to-handle) x 7 3/4" x 11 3/4"
Systainer: 15 1/2" x 11 1/2" x 17" (SYS 5 T-LOC Systainer)
WeightOrigin: 14.5 lbs
Packaged (with accessories) in Systainer: 23.5 lbs
