Dimar's Carbide Tipped Vertical Paneling bit has a profile cut into its edge so that the panel surface is flush with or proud of the frame. The most common method in modern cabinetry is the use of a panel raising cutter. The stiles and rails often have a profile cut into the inside edge of the outside face - usually a smaller version to match the profile of the panel.Two Flutes are ideal when fine finishing is a priority.Cuts most hardwoods and softwoods.Use on CNC, Hand-held routers, and table-mounted portable routers.
- Weight: 1.00 LBS
Diameter (D)1 1/8"
D11/4"
D2-
D3-
Shank (d)1/2"
Shank Length-
Cutting Length (B)1 1/2"
B2-
Overall Length (L)2 7/8"
Flutes2
Radius (R) 40mm
R2-
Depth-
Angle (A)-
A2-
Bore-
Videos Hide Videos Show Videos
- Weight: 1.00 LBS
- Shank: 1/2 in
- Profile: Beading Bits
